Frameset
Frame
Specialized A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible
Seat Binder
Alloy, quick release, 34.9
Suspension
Fork
SR Suntour XCM 29, 30mm stanchions, Rx Tune, coil spring, QR, 90/100mm travel (size-specific), 42mm offset
Cockpit
SeatPost
Alloy, 2-bolt clamp, 30.9mm
Stem
3D-forged alloy, 31.8mm, 7-degree rise
Handlebars
Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Saddle
Bridge Sport, Steel rails, 155/143mm
Grips
Specialized Trail Grips, lock-on
Brakes
Front Brake
Tektro BR-M275 Hydraulic Disc, 180/160mm
Rear Brake
Tektro BR-M275 Hydraulic Disc, 160mm
Drivetrain
Rear Derailleur
SHIMANO REAR DERAILLEUR, RD-U4000, CUES, GS 9-SPEED, TOP NORMAL, SHADOW DESIGN
Shift Levers
Shimano CUES SL-U4000-9R,RAPIDFIRE PLUS
Cassette
SHIMANO CUES CS-LG300-9, 9-SPEED, 11-41T
Chain
SHIMANO CN-LG500, W/QUICK-LINK
Crankset
Stout 1x, forged alloy
Bottom Bracket
Square-tapered, 73mm, internal bearings, 122.5mm spindle
Accessories
Pedals
SBC-54 Flat pedal
Wheels & Tires
Rims
Specialized alloy, disc only, double-wall, 25mm inner width, 32h
Front Hub
Formula SP-2120 6-Bolt, disc, 100x9mm spacing, quick-release
Spokes
Stainless, 14g
Rear Hub
Formula SP-2125, 6-Bolt freehub, disc, 135x9mm spacing, quick-release
Front Tire
Fast Trak Sport, 650b/29x2.35"
Rear Tire
Fast Trak Sport, 650b/29x2.35"
Inner Tubes
Standard 40mm SV 650B/29x1.75-2.4
Weight
Weight
13.38 kg (29 lb, 8.0 oz)
Weight Size
MD
